Nonwoven Polypropylene bag filters
We manufacture polypropylene filter bags for solid/liquid filtration, which are perfect for a temperature no higher than 80°C. Also, in applications demanding the chemical resistance for acid and alkalis. Polypropylene filter bags are calendared and thermally stabilized to prevent migration of fibers into the filtrate. They are produced most often in four standard sizes and are finished with steel snap ring or plastic self-sealing collar. Also available are non-standard filter bags and customized sizes and finishes with various options e.g., with tape, string, reinforcing, double handles, cylindrical bottom, V-shape bottom and many more, which we can produce in some working days as a manufacturer.
Media
Polypropylene nonwoven felt meets the EU/FDA regulations, it is treated with a glazed finishing surface to reduce fiber migration. Polypropylene material is perfect for removing both solid and gelatinous particles, it has high dirt loading capacity and is silicone free.
Micron rating
PO: 1; 5; 10; 25; 50; 100; 200 µm
Operating parameters
Maximum operating temperature 80°C
Chemical compatibility
| Substance | Compatibility |
|---|---|
| Organic solvents | Very good |
| Animal vegetable & petro Oils | Very good |
| Microorganism | Very good |
| Alkali | Very good |
| Organics agents | Very good |
| Oxidizing substances | Good |
| Mineral acid | Good |
Dimensions and filter area
| Size | Diameter × Length (mm) | Diameter × Length (inches) | Filter area (m2) |
|---|---|---|---|
| 2 | 177 × 815 | 7×32" | 0,50 |
| 1 | 177 × 410 | 7×16" | 0,25 |
| 4 | 103 × 385 | 4×15" | 0,09 |
| 3 | 103 × 230 | 4×9" | 0,05 |
| X1 | 152 × 508 | 6×20" | 0,23 |
Non-standard dimensions on request.
All our polypropylene filter bags are compliant to EC Directive 10/2011 and manufactured according to ISO 9001:2015 and ISO 14000:2015.
Features and advantages
- Micron rating from 1 to 200µm.
- Calendared and thermally stabilized polypropylene eliminates fiber migration into filtrate.
- All industry standard sizes and custom sizes available.
- Broad chemical compatibility and good permeability.
- High flow rate /low pressure drop.
- Sewn and fully welded construction.
- Choice of plastic ring or steel ring.
- Silicone free.
- Low cost and high quality.
- Simple construction and economical solutions for solid/liquid filtration.
- Mechanical resistance and high purification efficiency.
- Short delivery times, only some working days for delivery filter bags made according to customer’s specifications.
Application
- Filtration of circulating water.
- Preventing clogging of spray nozzles.
- Protecting catalyst beds.
- Machine protection.
- Removal of solid deposits.
- Elimination of undissolved particles.
- Removal of particles from surfaces and coatings.
- Purification of electrolyte solutions.
- Separation of large particles from suspensions.
- Condensate filtration.
- Filtering water for bottles and storage tanks.
- Filtering water used for washing poultry and meat.
- Removal of carbonized particles.
- Cooling tower water filtration.
- Filtering oil for reuse.
- Protecting refrigeration and air conditioning units.
- Safeguarding reverse osmosis systems.
- Filtering drinking water for broilers.
- Removing water from oil.
- Protecting glue applicators.
- Removing microplastic particles from water.
- Separating pulp from fruit juices.
